Seamless steel pipe quality inspection method

Seamless steel pipe quality inspection (test) method and instruments and equipment - chemical composition analysis of steel pipe

The product quality of seamless steel pipe must be inspected (tested) in accordance with product standards and technical specifications. Specific inspection (test) contents include chemical composition analysis, geometric dimension inspection, surface quality inspection, physical and chemical performance inspection, process performance inspection, metallographic analysis, and thread inspection and measurement of steel pipes. Its purpose is to ensure the quality of steel pipes to meet the corresponding standard regulations or technical conditions.

The chemical composition analysis of steel pipes can be carried out by chemical analysis or instrumental analysis. The so-called chemical analysis method is an analysis method based on the chemical reaction of substances. The instrumental analysis method is an analysis method based on the physical and chemical properties of substances. At present, the samples used for chemical analysis are divided into three types: smelting samples, ingot (bill) cuttings samples, and pipe samples. In order to improve the accuracy of sample analysis, the samples are not allowed to be contaminated. Melting samples generally use instrumental analysis, and finished pipe samples use chemical analysis and instrumental analysis.

The instruments commonly used for chemical composition analysis are: infrared carbon sulfur analyzer, direct reading spectrometer, x-ray fluorescence spectrometer, etc.

Infrared carbon sulfur analyzer is mainly used to analyze the content of C and S elements in iron and steel tubes, steelmaking raw materials, steel and other materials. It is a C and S element analysis instrument based on the principle of infrared absorption spectroscopy. It has high analysis accuracy, fast speed, simple operation, and the analysis process is controlled by computer.

Direct reading spectrometer is a photoelectric device for rapid quantitative analysis of block patterns. It is mainly used to analyze C, Si, Mn, P, S, Cr, Mo, Ni, Cu, Al, W, V, Ti, As,

Sn, B, Nb and other elements in steel. The analysis principle of the instrument is based on atomic emission technology. The entire analysis process is controlled by a computer, with high analysis accuracy, fast speed and simple operation.

X-ray fluorescence spectrometer is mainly used to analyze Si, Mn, P, S, Cr, Mo, Ni, Cu, Al, W, V, Ti, As, Sn, Nb, Ca, Mg, Fe, K, Na, Pb, Sb, B and other elements in steel. Its working principle is that the sample generates two rays under the irradiation of x-rays, that is, line fluorescence, and the qualitative and quantitative analysis of elements is carried out according to the generated spectrum and intensity.

The entire analysis process is controlled by a computer, with high analysis accuracy, less interference, simple operation, and the analysis sample is not damaged.
