General standards, sizes and pressure classes for pipe flanges

ANSI standard flange size table:

ANSI standard pipe flanges are commonly used in fluid control systems and piping systems in the United States and Canada. Commonly used ANSI standard flange size tables are as follows: ANSI B16.5, ANSI B16.47 (large diameter), and their sizes correspond to the following:

1. ANSI B16.5
The size of the clapper flange is 1/2"-24", and the pressure rating is 150-2500LBS; the size of the blind flange is 1/2"-24", and the pressure rating is 150-2500LBS; the size of the neck welding flange is 1/2"-24", and the pressure rating is 150-2500LBS; the size of the flat welding flange is 1/2"-24", and the pressure rating is 150-2500LBS.

2. ANSI B16.47

The size of the large diameter flange is 26"-60", and the pressure rating is 150-900LBS.

JIS standard flange size table:

JIS standard flanges are commonly used in fluid control systems and piping systems in Japan. Commonly used JIS standard flange size tables are as follows: JIS B2220, JIS B2201, and their sizes correspond to the following:

1. JIS B2220
The flange size is 10A-1500A, and the pressure level is 5K-63K.

2. JIS B2201
The flange size is 10A-1000A, and the pressure level is 2.5K-40K.

BS standard flange size table:

BS standard flanges are commonly used in fluid control systems and pipeline systems in the UK. Commonly used BS standard flange size tables are as follows: BS 10, BS 1560, BS 4504, and their sizes correspond to the following:

1. BS 10
The flange size is 1/2"-48", and the pressure level is PN0.6-PN40.

2. BS 1560
The flange size is 1/2"-24", and the pressure level is PN2.0-PN40.

3. BS 4504
The flange size is 1/2"-48", and the pressure level is PN2.5-PN100.

DIN standard flange size table:

DIN standard flanges are commonly used in fluid control systems and pipeline systems in Germany. The commonly used DIN standard flange size tables are as follows: DIN 2527, DIN 2576, DIN 2631 and DIN 2635, and their sizes correspond to the following:

1. DIN 2527
The flange size is DN10-DN600, and the pressure level is PN6-PN100.

2. DIN 2576
The flange size is DN10-DN1000, and the pressure level is PN6-PN40.

3. DIN 2631
The flange size is DN10-DN2000, and the pressure level is PN6-PN100.

4. DIN 2635
The flange size is DN10-DN1000, and the pressure level is PN6-PN100.

EN standard flange size table:

EN standard flanges are commonly used in fluid control systems and piping systems in Europe. Commonly used EN standard flange size tables are as follows: EN 1092-1, EN 1759-1, and their sizes correspond to the following:

1. EN 1092-1
The flange size is DN10-DN2000, and the pressure level is PN2.5-PN400.

2. EN 1759-1
The flange size is DN10-DN4000, and the pressure level is PN2.5-PN400.

Conclusion:
This article introduces the commonly used pipe flange size table, including ANSI, JIS, BS, DIN and EN standards, and introduces the types, sizes and standards of various flanges in detail. I hope that through the introduction of this article, you can better understand the size standards of flanges, which will facilitate your use and selection.
