How Should Oil Well Casing be Treated for Corrosion Protection?

Corrosion prevention treatment of oil well casing is a key measure to ensure its long-term stable operation in harsh underground environments. Here are some main corrosion prevention methods:

1. Strict Water Quality Management
Water Quality Compliance: First, it is necessary to ensure that the water quality in the injection well meets the standards to reduce corrosion sources introduced by water quality problems. This includes strengthening water quality testing and management, implementing separate injection of clean and contaminated water, and strengthening the cleaning of the main water pipeline to ensure that the water quality in the station and at the bottom of the well meets the standards.

2. Sterilization Treatment
Annularity Protection Fluid: For injection wells already in production, a sterilizing annular protection fluid should be added regularly to inhibit bacterial growth and reduce bacterial corrosion. This practice should be formalized and ensured to be added regularly.

3. Physical Protection
Rubber Rings and Centralizers: Given the accelerating effect of mechanical abrasion on oil well casing corrosion, it is recommended to install rubber rings on the tubing couplings or centralizers in areas of severe well deviation. This effectively prevents the tubing from scratching the casing during operation and water injection, and avoids prolonged contact between the tubing and casing on one side, thus reducing frictional corrosion.

4. High-Temperature Sterilization
High-Temperature Water or Steam: For severe under-scale bacterial corrosion, and considering the slow growth and easy killing of SRB (sulfate-reducing bacteria) at high temperatures, 100°C high-temperature water or steam can be periodically injected into the annulus to kill the under-scale SRB, thereby reducing bacterial corrosion.

5. Caution in Using Cathodic Protection and Coated Casing
Limitations: Before corrosion inside the casing of the water injection well is effectively controlled, the widespread use of cathodic protection and coated casing is not recommended. This is because these two methods may not be effective under certain conditions and may even exacerbate corrosion.

6. Surface Treatment and Material Selection
Surface Treatment: Appropriate treatment of the oil casing surface, such as sandblasting and cleaning, can improve coating adhesion and corrosion resistance.

Material Selection: Oil casing should be manufactured using materials with good corrosion resistance, such as stainless steel. While the cost may be higher, it can effectively extend the service life of the casing.

7. Anti-corrosion Coating
Coating Application: One or more anti-corrosion coatings, such as epoxy powder coatings or polyethylene coatings, are applied to the surface of the oil casing. These coatings effectively isolate corrosive media from contact with the casing substrate, thus providing corrosion protection.

In summary, corrosion protection for oil casing is a comprehensive process that requires attention to multiple aspects, including water quality management, sterilization treatment, physical protection, high-temperature sterilization, careful use of specific anti-corrosion methods, surface treatment and material selection, and anti-corrosion coatings, to ensure the long-term stable operation of the casing in harsh environments.
