Liquid Level Sensors working principle

In this article, we’ll cover everything you need to know about Liquid Level Sensors, from how they work to different types of applications.

What is a liquid level sensor?

Liquid level sensors are used to monitor and regulate levels of a particular free-flowing substance within a contained space. These substances are usually liquid, however liquid level sensor can also be used to monitor solids, such as powders. There are many different types of liquid level sensors, and they have several uses, both industrial and in the household for example.

How is liquid level sensor used?

Liquid level sensors are widely used industrially. Cars use liquid level sensor to monitor a variety of liquids, including fuel, oil and occasionally also specialist fluids such as power steering fluid. Liquid level sensor can also be found in industrial storage tanks, for slurries, and water level sensors can even be found in household appliances such as coffee machines. Basic liquid level sensors can be used to identify the point at which a liquid falls below a minimum or rises above a maximum level. Many liquid level sensors can detail the specific amount of liquid in a container relative to the minimum/maximum levels, to provide a continuous measurement of volume.

What are the different types of liquid level sensor?

There are a number of different types of level gauge used to detect the point level of a liquid. Some types of liquid level sensor use a magnetic float, which rises and falls with the liquid in the container. Once the liquid, and by extension, the magnet, reach a certain level, a reed magnetic switch is activated. Commonly, there is a switch towards the top and the bottom of the container, allowing detection of minimum and maximum levels of liquid. Many liquid level sensors also include a protective shield to protect the magnet from turbulence or interference from direct contact with the liquid.

Another common type of liquid level sensor is known as a Conductive Sensor. Only liquids which conduct electricity can be used in this liquid level sensor. A Conductive Sensor includes a source of power, usually of a fairly low voltage. At least two electrodes are placed within the container. When a conductive liquid reaches a certain point, it will come into contact with both a longer and a shorter electrode, and thus complete a circuit and activate an internal switch.

Pneumatic Sensors are also a fairly common occurrence with particularly hazardous liquids, or in systems where the use of electricity is not viable or possible. This is because the sensor itself does not come into direct contact with the liquid at all. The sensor detects the level of air between the liquid and the pneumatic sensor, then uses this to calculate the amount of liquid used to fill the remainder of the container. These types of liquid level sensors are also relatively cost-effective.

There are also other types of liquid level sensors which offer continuous measurement of liquids. Magnetostrictive liquid level sensors are similar in design to regular magnetic float sensors, yet the magnet level is measured using a magnetostrictive wire, which will react when its magnetic field is interrupted by the presence of the magnet. The exact point at which this interruption occurs can be determined by the distance between the bottom of the wire and the point of interference. Alternatives to this design include a magnetoresistive sensor, whereby an additional magnet is inserted onto the arm of the float, allowing accurate triangulation of the exact position of the magnets. This type of liquid level sensor is commonly used in conjunction with computer programs due to its accuracy. A non contact liquid level sensor features advanced signal processing technology in order to enable non contact liquid level detection.
